Name
*
First Name
Last Name
Email Address
*
Mailing Address
Providing your address is completely optional at this stage but it may help us put you in touch with innovan owners close by so that you could check one out in person.
Address 1
Address 2
City
State/Province
Zip/Postal Code
Country
VEHICLE DETAILS
PLEASE NOTE - Some vehicles sold in Australia may not be able to carry an innovan XS legally. Most “one ton” single cab, tray back utilities would be suitable, however most dual cab or extra cab vehicles would need to have the chassis lengthened to satisfy legal requirements.
If you indicate in the space provided below, the vehicle make and model to which you intend to fit the slide on, innovan will be in a position to make some suggestions regarding its suitability.
TRAY DETAILS
Please provide details on your trays construction for example aluminium, steel, steel with a wooden floor. It will also help to provide us with your trays manufacturer name and model number if known:
TRAY DIMENSIONS
Please provide dimensions in mm. Length from the back of the headboard to the back of the tray. Width from outside to outside. Height from the top edge of the lip on the tray to the top of the headboard. Height of the side lip.
SECTION A) XS STANDARD FEATURE LIST - NO NEED TO TICK "A" OPTIONS
A1. Construction method - lighter, stronger, GRP fully moulded construction
A2.* Lifting assist mechanisms for roof and beds- Pneumatic Rams (Gas Struts)
A3. Seals to prevent entry of dust & insects - Automotive
A4. Main Door -Easy access, Lockable, (Lever lock from inside and key from outside)
A5. Cover on water tank filling port -Lockable
A6. External Access Doors to Storage - Lockable, Keyed alike ( 2 with roof down, 5 with roof up)
A7. Stairs -wide, safe aluminium, folding, Stairs lock awning in place
A8. Dinette - Roll-Out Dining Table and Comfortable Upholstered Seats (Blue colour standard)
A9. Mattresses - Comfortable 1800mm. x 760 mm. top quality (Blueish colour standard)
A10. Storage space - Approx. 3,000 litres (varies with inclusions)
A11. Gas Storage Compartment to hold two gas bottles, Lockable
A12. Beds - "InnoSpace" Self Raising (with internal storage and safety props)
A13. Storage Compartments behind seats (Blue colour lid standard)
A14. Kitchen Utensil Storage (Internal and External access)
A15. Work Bench / Kitchen-utensils Storage Cover (Blue colour standard)
A16. Storage Compartment below Utensils storage
A17. Coloured hinged Doors on chest high cupboards(Blue colour standard)
A18. Lockable Door for Vanity Recess
A19. Mirror on inside of the vanity recess door
A20. Wiring Loom - 12 volt with Andersen plug to connect to vehicle at the front drivers side corner
A21. Power Outlets - 3 x 12V (2 internal and 1 external cigarette lighter sockets )
A22. LIGHTS - LED -(2 exterior ,2 storage compartment , 6 ajustable internal reading and work)
A23. Centre console with LED Strip-light, drop-down door and lined interior
A24. Front window -(double glazed, hinge opening, with adjustable blind and insect screen)
A25. Rear Window - screened, sliding
A26. Roof Lining- Fully lined interior
A27. Grab handle to facilitate entry and exit when using the stairs
A28. Water Pump - 12V, 11 litres/minute with Particle Filter and Plumbing
A29.* Water tanks –110 litres -(2 X 55 litre tanks connected)
A30. Plumbing System to allow the level of water in the tanks to be seen.
A31. Faucet in Vanity Recess
A32. Shower unit with extension hose, ajustable head, and chrome lever mixer
A33. Sink and Drainer - Dometic with glass lid and hot/cold mixer tap
A34. Floor Covering -Walkatex (stain resistant, removable and washable)
A35. Fire Extinguisher
A36. Stainless steel Jack Mounts to attach legs to slide-on for freestanding mode
SECTION B) ADDITIONAL FEATURES RELATED TO GAS FITMENT
Please click the box on the left-hand side of any item that you would like to have included in your unit. The tick produced will indicate that you want this item included in the pricing.
B1. Gas Bottles X 2, Regulator,Fittings, Piping and Certificate
B2. Vent in the main door ( necessary when gas appliances are fitted internally)
B3. Canopy Hatch with ventilation, skylight, blind and insect screen. (Also necessary)
B4. Flush Mounted Internal Cooktop (Dometic 3 burner with glass lid)
B5.* Gas Hot Water System (Dometic Truma B 14)
B6. External Stainless steel slide out Kitchen with 2 burner cooktop, workbench and sink
B7. Stainless steel barbecue (Bravo Marine) mounted on roll out kitchen-(with bayonet hose end)
B8. Stainless oven wire insert to convert Bravo barbecue to Stove Top and Oven
B9. Gas air heater – 12 V ignition ( TRUMA E 2400)
SECTION C) ADDITIONAL FEATURES RELATED TO ELECTRICITY
Please click the box on the left-hand side of any item that you would like to have included in your unit. The tick produced will indicate that you want this item included in the pricing.
C1. Heavy duty 12 V wiring system with 50 amp Anderson plug to connect to vehicle plug.
C2. Refrigerator/Freezer -12V, 85L EvaKool -(BD50 Danfos compressor)
C3. Battery-12 Volt 100 amp hour AGM (glass mat) deep cycle battery
C4. A second battery -12 Volt 100 amp hour AGM (glass mat) deep cycle
C5.* Voltage-booster to 14.4 Volt DC,20 amp, isolator and Solar Panel Regulator (CTEK D250S)
C6. Additional 12V Power Point
C7. Inverter (12V to 240V)-Modified Square wave
C7a. 150W = $70
C7b. 300W = $120
C7c. 550W = $190
C8. Inverter (12V to 240V) - VICTRON pure sine wave
C8a. 150W = $210
C8b. 300W = $270
C8c. 800W = $670
C9. Solar panel with regulator- – folding, fixed or portable mode.
C10. Power circuit – 240 V, with safety switches and with one double power point
C11. Air-conditioner – 240 V reverse cycle – Truma Saphir Comfort
C12.* Battery maintenance system 7 amp CTEK (Connected from the 240 V circuit to the 12 V circuit )
C13. Additional 240V Power Point (Double Pole)
SECTION D) ADDITIONAL FEATURES RELATED TO CONVENIENCE AND COMFORT
Please click the box on the left-hand side of any item that you would like to have included in your unit. The tick produced will indicate that you want this item included in the pricing.
D1. Legs for freestanding mode – wind up / wind down, with locating pin for height adjustment.
D2. "Innoshield" roll out awning system with bracing
D3.* Side Windows-2 X Large 900X500-(screened, tinted, sliding)
D4.* Roll Out Toilet draw & drop-down Support Door (Blue colour standard on outside of door)
D5.* Toilet with hold down brackets (Domestic 976 or equivalent-19 litres)
D6. Water filter system (Washable pre-filter and secondary to remove bacteria )- Tap in vanity unit
D7. Plumbing system to allow pumping of water (or filtered water) to tanks from an external source
D8. Vinyl shower cubicle with floor and fitting for drain hose
D9. Awning extension -provides walls on awning or extra shade-( poles and ropes not included)
D10. Inserts to convert Single Beds to "Queen Size"
D11. Bracket to lock awning in the semi closed position
D12. Spring support arm on the three large storage compartment doors
D13. Vinyl Covers to protect Windows from rain
D14. Insect screen for rear door
D15. Replacement filter cartridge for long-term travel
D16. Awning mounted on the side of the roof
D17. Extra sail track to mount extra awning
D18.* Reversing video system – 5 inch LCD monitor and CAM 50C LED colour camera
SECTION E) ALTERNATIVE OPTIONS FOR FEATURES MARKED WITH * ABOVE
Please click the box on the left-hand side of any item that you would like to have included in your unit. The tick produced will indicate that you want this item included in the pricing rather than the related item in the previous sections.
E1. Change (A2) Gas struts for raising and lowering the roof to Electrically driven Actuators.
E2. Change (A29) Include more than 2 water tanks
E3. Change (B5) Gas Hot Water system to Gas/240volts electricity (240 Volt Circuit required)
E4. Change (C5) Voltage-boosting Battery Charger, 20 amp to 40 amp (with solar panel regulator)
E5. Change (C12) CTEK Battery maintenance system- 7 amp to 15 amp system
E6. Change (D3) side windows to 900 x 550 mm hinged, tinted, double glazed, with blind and screen
E7. Change (D4 & D5) to have Internal Access Door to area under sink if the toilet door is not fitted
E8. Change (D18) Reversing Video System from 5 inch to 7 inch
SHIPPING ADDRESS
If you would like innovan to arrange shipping of your unit to you from our manufacturing facility please provide the destination shipping address details so that a quote can be obtained and added to your product investment price. If your shipping address is the same as your mailing address simply type same as above. Alternatively, if you want to take advantage of our holiday self collection offer please write HOLIDAY SELF COLLECTION in the address bar below. For more information on this offer refer to the left hand webpage menu tab.
Address 1
Address 2
City
State/Province
Zip/Postal Code
Country
NEWSLETTER SIGN UP
We would love to keep in touch outside of the product enquiry process. Tick YES if you would like to receive our e-newsletters and connection innovan adventure group.
YES Please
No Thanks
